NTMFS011N15MC
NTMFS011N15MC is 150V 78A N-Channel Power MOSFET manufactured by onsemi.
Features
- Small Footprint (5 x 6 mm) for pact Design
- Low RDS(on) to Minimize Conduction Losses
- Low QG and Capacitance to Minimize Driver Losses
- These Devices are Pb-Free, Halogen Free/BFR Free and are Ro HS pliant
Typical Applications
- Synchronous Rectification
- AC-DC and DC-DC Power Supplies
- AC-DC Adapters (USB PD) SR
- Load Switch
MAXIMUM RATINGS (TJ = 25 °C, Unless otherwise specified)
Parameter
Symbol Value Unit
Drain-to-Source Breakdown Voltage
V(BR)DSS
Gate-to-Source Voltage
±20
Continuous Drain
Steady TC = 25 °C
Current Rq JC
State
(Note 2)
Power Dissipation
Rq JC (Note 2)
Continuous Drain
Steady TA = 25 °C
Current Rq JA
State
(Note 1, 2)
147 W 10.7 A
Power Dissipation Rq JA (Note 1, 2)
Pulsed Drain Current TA = 25 °C, tp = 250 ms
Operating Junction and Storage...
