Datasheet Summary
MOSFET
- Power, Single N-Channel, T10, STD Gate, SO8FL
80 V, 13.8 mW, 35 A
Features
- Low QRR, Soft Recovery Body Diode
- Low RDS(on) to Minimize Conduction Losses
- AEC- Q101 Qualified and PPAP Capable
- These Devices are Pb- Free, Halogen Free/BFR Free and are RoHS pliant
Applications
- Synchronous Rectification (SR) in DC- DC and AC- DC
- Motor Drives
- Automotive 48 V System
MAXIMUM RATINGS (TJ = 25°C unless otherwise stated)
Parameter
Symbol Value Unit
Drain- to- Source Voltage
VDSS
Gate- to- Source Voltage
±20
Continuous Drain Current (Note 1)
TC = 25°C
TC = 100°C
Power Dissipation (Note 1)
TC = 25°C
Pulsed Drain...
