MBR640 - (MBR640 - MBR6200) SCHOTTKY BARRIER RECTIFIERS

Download the MBR640 datasheet PDF (MBR6100 included). The manufacturer datasheet provides complete specifications, pinout details, electrical characteristics, and typical applications for (mbr640 - mbr6200) schottky barrier rectifiers.

Features

  • Plastic package has Underwriters Laboratory Flammability Classification 94V-O utilizing Flame Retardant Epoxy Molding Compound.
  • Exceeds environmental standards of MIL-S-19500/228.
  • Low power loss, high efficiency.
  • Low forwrd voltge, high current capability.
  • High surge capacity.
  • For use in low voltage,high frequency inverters free wheeling , and polarlity protection.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (MBR6100_PanJitInternational.pdf) that lists specifications for multiple related part numbers.

📁 Similar Datasheet

  • MBR600100CT - Schottky Power Diode (Naina Semiconductor)
  • MBR600100CT - Silicon Power Schottky Diode (America Semiconductor)
  • MBR600100CT - Silicon Power Schottky Diode (GeneSiC)
  • MBR600100CTR - Schottky Power Diode (Naina Semiconductor)
  • MBR600100CTR - Silicon Power Schottky Diode (America Semiconductor)
  • MBR600100CTR - Silicon Power Schottky Diode (GeneSiC)
  • MBR60020CT - SCHOTTKY DIODES (TRANSYS)
  • MBR60020CT - Schottky Power Diode (Naina Semiconductor)
  • MBR60020CT - Silicon Power Schottky Diode (America Semiconductor)
  • MBR60020CT - Silicon Power Schottky Diode (GeneSiC)
Other Datasheets by Pan Jit International
  • MBR645 - (MBR640 - MBR6200) SCHOTTKY BARRIER RECTIFIERS
  • MBR60100PT - Schottky Barrier Rectifiers
  • MBR60150PT - Schottky Barrier Rectifiers
  • MBR60200PT - Schottky Barrier Rectifiers
  • MBR6020PT - (MBR6020PT - MBR60100PT) 60 AMPERES SCHOTTKY BARRIER RECTIFIERS
  • MBR6040PT - Schottky Barrier Rectifiers
  • MBR6045PT - (MBR6020PT - MBR60100PT) 60 AMPERES SCHOTTKY BARRIER RECTIFIERS
  • MBR6060PT - (MBR6020PT - MBR60100PT) 60 AMPERES SCHOTTKY BARRIER RECTIFIERS

Full PDF Text Transcription

Click to expand full text
www.DataSheet.co.kr MBR640~MBR6200 SCHOTTKY BARRIER RECTIFIERS VOLTAGE FEATURES • Plastic package has Underwriters Laboratory Flammability Classification 94V-O utilizing Flame Retardant Epoxy Molding Compound. • Exceeds environmental standards of MIL-S-19500/228 • Low power loss, high efficiency. • Low forwrd voltge, high current capability • High surge capacity. • For use in low voltage,high frequency inverters free wheeling , and polarlity protection applications. • In compliance with EU RoHS 2002/95/EC directives .058(1.47) .042(1.07) 40 to 200 Volts CURRENT 6.0 Ampers PRELIMINARY MECHANICALDATA • Case: TO-220AC full molded plastic package • Terminals: Lead solderable per MIL-STD-750, Method 2026 • Polarity: As marked. • Mounting Position: Any • Weight: 0.0655 ounces, 1.859 grams.
