Puya Semiconductor PY32F030
The PY32F030 series of microcontrollers are suitable for various application scenarios, such as controllers, portable devices, PC peripherals, gaming and GPS platforms, industrial applications.| Part No. | PY32F030 |
|---|---|
| Datasheet | PY32F030 Download |
| Manufacturer |  Puya Semiconductor |
| Description | 32-bit microcontroller |
| Buy | Stock & Price |
FEATURES
● Core — 32-bit ARM® Cortex® - M0+ CPU — Up to 48 MHz operating frequency● Memories — Maximum 64 KB of Flash memory — Up to 8 KB SRAM
● Clock system — Internal 4/8/16/22.12/24 MHz RC Oscillator (HSI) — Internal 32.768 kHz RC oscillator (LSI) — 4 to 32 MHz crystal oscillator (HSE) — 32.768 kHz low speed crystal oscillator (LSE) — PLL (supports 2 octaves for HSI or HSE)
● Power management and reset — Operating voltage(x6 version): 1.7 to 5.5 V — Operating voltage(x7 version): 2.0 to 5.5 V — Low power modes: Sleep and Stop — Power-on/Power-down reset (POR/PDR) — Brownout Detect Reset (BOR) — Programmable Voltage Detection (PVD)
● General purpose input and output (I/O) — Up to 30 I/Os, all available as external interrupts
● 3-channel DMA controller
● 1 x 12-bit ADC — Supports up to 10 external input channels — Input voltage conversion range: 0 ~ VCC
● Timers — A 16 bits advanced control timer (TIM1) PY32F030 Series 32-bit ARM ® Cortex ® -M0+ Microcontroller — 4 general purpose 16...
