GVGR-S11SD
GVGR-S11SD is PN-type Photodiode manufactured by ROITHNER.
Rev. 10 / 2018
- PN-type Photodiode
- Indium Gallium Nitride Based Material
- 295
- 490 nm
- Photovoltaic Operation Mode
- SMD 3528, 3.15 x 2.80 x 1.90 mm
Description
GVRG-S11SD is a Photodiode working in the spectral range of 295
- 490 nm. It contains an Indium Gallium Nitride based chip die, housed into SMD 3528 package, is a great solution, as example for blue LED monitoring, UV curing or UV LED...
