GVGR-S11SD Description
GVRG-S11SD is a Photodiode working in the spectral range of 295 490 nm. It contains an Indium Gallium Nitride based chip die, housed into SMD 3528 package, is a great solution, as example for blue LED monitoring, UV curing or UV LED monitoring. 0.07 295 490 0.0162 TCASE = 25°C Unit nA nA A/W nm mm2 .roithner-laser.
