2SD1583-Z
DESCRIPTION
<R>
The 2SD1583-Z is designed for Audio Frequency Amplifier and
Switching, especially in Hybrid Integrated Circuits.
FEATURES
- High h FE: h FE = 800 to 3200
- Low VCE(sat): VCE(sat) = 0.18 V TYP.
ABSOLUTE MAXIMUM RATINGS (TA = 25°C)
Collector to Base Voltage
VCBO
Collector to Emitter Voltage
VCEO
Base to Emitter Voltage
VEBO
Collector Current (DC)
IC(DC)
Collector Current (pulse) Note 1
IC(pulse)
Total Power Dissipation (TA = 25°C) Note 2
Junction Temperature
Tj
°C
Storage Temperature
Tstg
- 55 to +150
°C
PACKAGE DRAWING (Unit: mm)
6.5 ±0.2 5.0 ±0.2 4.4 ±0.2
Note
+0.2
-...
