RT8980H Description
The RT8980H is a USB Type-C audio interface switch IC which supports analog audio headsets for mobile devices. The RT8980H provides a general USB Type−C port to pass USB2.0 data signal (DP, DN), sideband use signal, analog audio R L signal, and analog microphone signal. The RT8980H also supports high voltage protection for USB port and SBU port on USB Type−C receptacle side.
RT8980H Key Features
- Power Supply : VCC = 2.7V to 5.5V
