Datasheet Details
| Part number | STW12NK90Z |
|---|---|
| Manufacturer | STMicroelectronics |
| File Size | 479.59 KB |
| Description | N-CHANNEL Power MOSFET |
| Datasheet | STW12NK90Z_STMicroelectronics.pdf |
|
|
Overview: STW12NK90Z N-channel 900 V, 0.72 Ω, 11 A TO-247 Zener-protected SuperMESH™ Power.
| Part number | STW12NK90Z |
|---|---|
| Manufacturer | STMicroelectronics |
| File Size | 479.59 KB |
| Description | N-CHANNEL Power MOSFET |
| Datasheet | STW12NK90Z_STMicroelectronics.pdf |
|
|
|
This device is made using the SuperMESH™ Power MOSFET technology that is obtained through an extreme optimization of ST’s well established strip-based PowerMESH™ layout.
In addition to pushing on-resistance significantly down, special care is taken to ensure a very good dv/dt capability for the most demanding applications.
Such series complements ST full range of high voltage MOSFETs including revolutionary MDmesh™ products.
