M24C04-F - 4-Kbit serial I2C bus EEPROM

Product Overview

STMicroelectronics

📥 Download Datasheet

M24C04-F 4-Kbit serial I2C bus EEPROM by STMicroelectronics - Datasheet Preview — Datasheet preview – M24C04-F

Datasheet Details

Part number	M24C04-F
Manufacturer	STMicroelectronics
File Size	819.90 KB
Description	4-Kbit serial I2C bus EEPROM
Datasheet	M24C04-F Datasheet
Note	This datasheet PDF includes multiple part numbers: M24C04-F, M24C04-W. Please refer to the document for exact specifications by model.
Additional preview pages of the M24C04-F datasheet.

Product details

Description

The M24C04 is a 4-Kbit I2C-compatible EEPROM (electrically erasable programmable memory) organized as 512 × 8 bits.

Features

Compatible with following I2C bus modes:.
400 kHz.
100 kHz.
Memory array:.
4 Kbit (512 byte) of EEPROM.
Page size: 16 byte.
Single supply voltage:.
M24C04-W: 2.5 V to 5.5 V.
M24C04-R: 1.8 V to 5.5 V.
M24C04-F: 1.7 V to 5.5 V 1.6 V to 5.5 V (under temperature constraint).
Write:.
Byte write within 5 ms.
Page write within 5 ms.
Operating temperature range:.
from -.
