2SB1323 Datasheet Epitaxial Planar Silicon Transistor

Manufacturer: SANYO (now Panasonic)

Overview: Ordering number:EN3129 PNP/NPN Epitaxial Planar Silicon Transistors 2SB1323/2SD1997 Compact Motor Driver.

Datasheet Details

Part number	2SB1323
Manufacturer	SANYO (now Panasonic)
File Size	81.66 KB
Description	Epitaxial Planar Silicon Transistor
Datasheet	2SB1323_SanyoSemiconDevice.pdf

Contains input resistance (R1), base-to-emitter resistance (RBE).
Contains diode between collector and emitter.
Low saturation voltage.
Large current capacity.
Small-sized package making it easy to provide high- density, small-sized hybrid ICs. Package Dimensions unit:mm 2038 [2SB1323/2SD1997] ( ) : 2SB1323 Specifications Absolute Maximum Ratings at Ta = 25˚C Parameter Symbol Collector-to-Base Voltage Collector-to-Emitter Voltage Emitter-to-Base Voltage Collec.
