SA21340PDAD Overview
Description
The SA21340PDAD is an automotive grade, 300 mA high-current capacity linear regulator with ultra-low ground current and low dropout voltage. The device provides a fixed output voltage of 3.3V, also offers protective features, including over current limiting, output short-circuit protection, and over-temperature protection.
Key Features
- Wide Input Voltage Range: 4V to 36V
- Fixed 3.3V Output Voltage
- Output Voltage Accuracy: ±2% over Temperature
- Low Dropout Voltage of 300mV at Full Load 300mA
- 300mA Maximum Load Current
