SY2A27357D
Description
The SY2A27357D is an automotive grade, 150m A high current capacity linear regulator. It fixed the output voltage at 5V, which features ultra-low ground current and low drop out voltage. The device offers protection features includes over current limit, output short protection and over temperature protection. The SY2A27357D is available in a pact SOT23-5 package.
Typical Application
Features
- Wide Input Voltage Range: 4V to 36V
- 150m A Maximum Load Current
- Low Dropout Voltage (150m V @ 150m A)
- Ultra-low Quiescent Current (15 µA typ.)
- Stability with Tantalum or Ceramic Capacitors
- Excellent Load and Line Regulation
- Over Current Protection
- Thermal Shutdown
- pact SOT23-5 Package
- Automotive AEC- Q100 Grade 1 Qualified
Applications
- Note Book
- Cell Phone
- Automotive LED Lighting ECU
- Automotive Body Modules
VIN: 4V to 36V
CIN 10μF
COUT 4.7μF
Figure 1 Schematic Diagram
Ordering Information
Ordering Part Number
SY2A27357DAAA
Packag...
