SY6280D Description
The SY6280D is an ultra-low RDS(ON) Power Distribution switch with current limit to protect the power source from over current and short circuit conditions. It incorporates over temperature protection and reverse blocking function. Ordering Information SY6280 □(□□ □) Package Code Optional Spec Code Ordering Number Package Type Note SY6280DAAT SOT23-5 SY6280D Low Loss Power Distribution Switch with Programmable...
SY6280D Key Features
- Input Voltage: 2.5V to 5.5V
- Extremely Low Power Path Resistance: 65mΩ (typ.)
- Adjustable Current Limit from 100mA to 2A
- Over Temperature Shutdown and Automatic Retry
- Reverse Blocking (No Body Diode)
- Built-in Soft-start
- RoHS pliant and Halogen Free
- pact Package Minimizes the Board Space
