2N7481U3 Overview
Key Specifications
Mount Type: Surface Mount
Pins: 3
Max Operating Temp: 150 °C
Min Operating Temp: -55 °C
Description
VPT Components' new radiation-tolerant power MOSFETs are now available in die and standard U3 package options, as well as custom packaging for HiRel environments. Applications within the military, aerospace, medical, nuclear power generation, and high-energy physics research laboratories can benefit from the use of this new series of MOSFETs.
Key Features
- Available in JANSR, JANTXVR Per MIL-PRF-19500/703
- TO-276AA, SMD-0.5 (U3) package
- Hermetically Sealed Rev. V7 FIGURE 1: TO-276AA, SMD-0.5 (U3) Package
