1N4151W - Small Signal Fast Switching Diode

Vishay

Key Features

Silicon epitaxial planar diode.
Fast switching diode.
AEC-Q101 qualified available.
Base P/N-E3 - RoHS-compliant, commercial grade.
Base P/N-HE3 - RoHS-compliant, AEC-Q101 qualified.
Material categorization: for definitions of compliance please see www. vishay. com/doc?99912         PARTS TABLE PART.

1N4151W small signal fast switching diode by Vishay - Datasheet Preview

Datasheet Details

Part number	1N4151W
Manufacturer	Vishay
File Size	102.38 KB
Description	Small Signal Fast Switching Diode
Datasheet	1N4151W Datasheet

📁 Similar Datasheet

Part Number	Description	Manufacturer
1N4151W	SMALL SIGNAL DIODES	Kexin
1N4151W	SURFACE MOUNT FAST SWITCHING DIODE	Sunmate
1N4151W	SURFACE MOUNT FAST SWITCHING DIODE	Sangdest Microelectronics
1N4151WS	SURFACE MOUNT FAST SWITCHING DIODE	Sunmate
1N4151	Silicon Switching Diode	Central Semiconductor

Other Datasheets by Vishay

Part Number	Description
1N4151W-G	Small Signal Fast Switching Diode
1N4151WS	Small Signal Fast Switching Diode
1N4151WS-G	Small Signal Fast Switching Diode
1N4151	Small Signal Fast Switching Diodes
1N4150	Small Signal Fast Switching Diodes

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text

www.vishay.com 1N4151W Vishay Semiconductors Small Signal Fast Switching Diode DESIGN SUPPORT TOOLS click logo to get started Models Available MECHANICAL DATA Case: SOD-123 Weight: approx. 10.3 mg Packaging codes / options: 18/10K per 13" reel (8 mm tape), 10K/box 08/3K per 7" reel (8 mm tape), 15K/box FEATURES • Silicon epitaxial planar diode • Fast switching diode • AEC-Q101 qualified available • Base P/N-E3 - RoHS-compliant, commercial grade • Base P/N-HE3 - RoHS-compliant, AEC-Q101 qualified • Material categorization: for definitions of compliance please see www.vishay.
