W83301DR-O
Description
The W83301DR-O is an ACPI-pliant controller for microprocessor and other puter applications.
Key Features
- Connect this pin to the gate of a suitable N-channel MOSFET for driving bus termination regulator output
- BTSEN BTSINK 3 BT Sense
- Connect this pin to the bus termination regulator output
- This pin is used to drive a N-channel MOSFET to sink the redundant current in the high-speed bus
- Reserved 5 Function Reserved
- Pull up this pin to +5VSB through a 1.5 Kohm resistor
- Vss 6 Power Ground
- Connect this pin to ground
- 5VSB C1 7 Power 5VSB
- Attach flying capacitor between this pin and C2 to generate internally used high voltage from 5V power supply
