WF24MTLAJDNN0
WF24MTLAJDNN0 is TFT Display manufactured by WINSTAR Display.
Winstar Display Co., LTD
華凌光電股份有限公司
WEB: https://.winstar..tw E-mail: sales@winstar..tw
SPECIFICATION
MODULE NO.: WF24MTLAJDNN0#
General Specifications
Item
Dimension
Unit
Size
2.4 inch
Dot Matrix
240 x RGB x 320(TFT) dots
Module dimension
42.72(W) x 60.26(H) x 2.25(D) mm
Active area
36.72 x 48.96 mm
Pixel Pitch
0.153 x 0.153 mm
LCD type
TFT, Normally White, Transmissive
TFT Interface
TFT Driver IC
ST7789V or Equivalent
View Direction
6 o’clock
Gray Scale Inversion Direction 12 o’clock
Aspect Ratio
Portrait
Backlight...
