WF39BSQASDNN0
WF39BSQASDNN0 is TFT Display manufactured by WINSTAR Display.
Winstar Display Co., LTD
華凌光電股份有限公司
WEB: https://.winstar..tw E-mail: sales@winstar..tw
SPECIFICATION
MODULE NO.:
WF39BSQASDNN0#
General Specifications
Item
Dimension
Unit
Size
3.9 inch
Dot Matrix
480 x 128 x RGB (TFT) dots
Module dimension
105.5(W) x 37.0(H) x 3.05(D) mm
Active area
95.04 x 25.34 mm
Dot pitch
0.066(W) x 0.198(H) mm
LCD type
TFT, Normally White, Transmissive
View Direction
6 o’clock
Gray Scale Inversion Direction 12 o’clock
Aspect Ratio
Bar Type
TFT Driver IC
HX8278-A or Equal
TFT...
