Description
Backlight LED Cathode Backlight LED Anode. System Ground Power supply for logic operation Data bus Data bus Data bus System Ground Pixel clock signal Display on/off control Horizontal Sync signal Vrtical Sync signal No connection (Option DE) No connection System Ground No connection (Option XR for RTP) No connection (Option YD for RTP) No connection (Option XL for RTP) No connection (Option YU for RTP) WF39CTIASDNN0# 第 4 頁，共 5 頁 Contour Drawing 3.50 50.63 20.50±0.1 19.50±0.1 18.55±0.5 0.30±0.05 Contact side 0.30±0.05 Stiffener 47.19±0.5 KA B G R 5.23 4.23 Remove tape 37.00±0.2 27.34 VA 25.34 AA 95.04 AA 97.04 VA 105.50±0.2 3.58 2.58 3.05±0.2 5.00 22.45 Black tape 1 VLED- 2 VLED+ 3 GND 4 VCC 5 R0 6 R1 7 R2 8 R3 9 R4 10 R5 11 R6 12 R7 13 G0 14 G1 15 G2 16 G3 17 G4 18 G5 19 G6 20 G7 21 B0 22 B1 23 B2 24 B3 25 B4 26 B5 27 B6 28 B7 29 GND 30 DCLK 31 DISP 32 HSYNC 33 VSYNC 34 NC 35 NC 36 GND 37 NC 38 NC 39 NC 40 NC The non-specified tolerance of dimension is ±0.3 mm.
