Datasheet Summary
Winstar Display Co., LTD
華凌光電股份有限公司
WEB: https://.winstar..tw E-mail: sales@winstar..tw
SPECIFICATION
MODULE NO.: WF70D3TIAGDNT0#
General Specifications
Item
Dimension
Unit
Size
7.0 inch
Dot Matrix
800 x RGB x 480 (TFT) dots
Module dimension
165 x 100.0 x 7.2 mm
Active area
154.08 x 85.92 mm
Pixel Pitch
0.1926 x 0.179 mm
LCD type
TFT, Normally White, Transmissive
View Direction
12 o’clock
Gray Scale Inversion Direction 6 o’clock
Aspect Ratio
16:9
Backlight Type
LED ,Normally White
Color arrangement
RGB-...
