XL534 - Latching Hall Switch Sensor

Description

The XL534 is a latching Hall switch sensor that optimized for wide voltage, low quiescent current and wide temperature range.

XL534 supports a power supply voltage of up to 85V and provide a load capacity of up to 40mA.

Features

  • Wide Operating Voltage Range：3.3V~80V.
  • Low Quiescent Current : 1.5mA.
  • Device HBM ESD Classification Level Class3B.
  • Reverse Supply Protection.
  • Excellent Magnetic Field Symmetry.
  • 40mA Load Capacity.
  • SOT23-3 package.
  • Magnetic Field Operate Point : 80Gs.
  • Magnetic Field Release Point : -80Gs.

📥 Download Datasheet

Datasheet preview – XL534

Datasheet Details

Part number XL534
Manufacturer XLSEMI
File Size 696.00 KB
Description Latching Hall Switch Sensor
Datasheet download datasheet XL534 Datasheet
Additional preview pages of the XL534 datasheet.

📁 Similar Datasheet

  • XL551 - LinCMOS process (XINLUDA)
Other Datasheets by XLSEMI
  • XL5002 - 600V 0.5A Switching Current Buck PFM LED Constant Current Driver
  • XL5003 - 600V 0.5A Switching Current Buck PFM LED Constant Current Driver
  • XL5004 - 600V 0.5A AC TO DC PFM LED Lighting Controller
  • XL5006 - 600V 0.5A Switching Current Buck PFM LED Constant Current Driver
  • XL561 - Omnipolar Hall Switch Sensor
  • XL591 - Linear Hall Sensor

Full PDF Text Transcription

Click to expand full text
Datasheet Latching Hall Switch Sensor XL534 Features  Wide Operating Voltage Range：3.3V~80V  Low Quiescent Current : 1.5mA  Device HBM ESD Classification Level Class3B  Reverse Supply Protection  Excellent Magnetic Field Symmetry  40mA Load Capacity  SOT23-3 package  Magnetic Field Operate Point : 80Gs  Magnetic Field Release Point : -80Gs Applications  Power Tools  Flow Meters  Valve and Solenoid Status  Brushless DC Motors  Tachometers General Description The XL534 is a latching Hall switch sensor that optimized for wide voltage, low quiescent current and wide temperature range. XL534 supports a power supply voltage of up to 85V and provide a load capacity of up to 40mA. Widely used in automotive electronics, industrial control and other applications.
