Datasheet Summary
Discontinuation Notice
Discontinuation date:
2/1/2023
Remended replacement: AZ7709
10A SPDT SUBMINIATURE POWER RELAY Features
- Small footprint
- Low cost
- Class B insulation standard
- Epoxy sealed version available
- 10 Amp switching
- UL, CUR file E44211 d CONTACTS
Arrangement e Ratings
SPST (1 Form A) SPDT (1 Form C)
Resistive load:
Max. switched power: 150W 1250VA
Max. switched current: 10A tinu Rated Load n UL, CUR
Max. switched voltage: 30VDC- or 277VAC
- Note: If switching voltage is greater than 30 VDC, special precautions must be taken. Please contact the factory.
10A at 125VAC 5A at 250VAC 1/4HP at 120/240/277VAC TV-5 at 120VAC 24VA at 24VAC 125VA at...
