AZ767 - SPDT SUBMINIATURE POWER RELAY

ZETTLER Electronics

Key Features

www. datasheet4u. com.
Low cost 10 Amp switching Epoxy sealed version available UL, CUR file E44211.

AZ767 spdt subminiature power relay by ZETTLER Electronics - Datasheet Preview

Datasheet Details

Part number	AZ767
Manufacturer	ZETTLER Electronics
File Size	78.97 KB
Description	SPDT SUBMINIATURE POWER RELAY
Datasheet	AZ767 Datasheet

📁 Similar Datasheet

Part Number	Description	Manufacturer
AZ761	12A SPDT Minuature Power Relay	Zettler relays
AZ762P	POWER RELAY	Zettler
AZ762T	16 AMP HIGH INRUSH MINIATURE POWER RELAY	Zettler
AZ7695	MINIATURE POWER RELAY	American Zettler
AZ7023R	VOLTAGE DETECTOR	BCD Semiconductor

Other Datasheets by ZETTLER Electronics

Part Number	Description
AZ760	20 AMP MINIATURE POWER RELAY
AZ762	16A SPDT MINIATURE POWER RELAY
AZ763	12A SPDT MINIATURE POWER RELAY
AZ764	16A SPDT MINIATURE POWER RELAY
AZ766	SPST SUBMINIATURE POWER RELAY

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text

AZ767 SPDT SUBMINIATURE POWER RELAY FEATURES www.datasheet4u.com • • • • Low cost 10 Amp switching Epoxy sealed version available UL, CUR file E44211 CONTACTS Arrangement Ratings SPST-NO Standard coil Sensitive coil SPDT GENERAL DATA SPST (1 Form A) SPDT (1 Form C) Resistive Load: Max. Max. Max. Max. switched switched switched switched power: 150 W or 1250 VA current: 5 ADC or 10 AAC power: 90 W or 750 VA current: 3 A Life Expectancy Mechanical Electrical Operate Time (typical) Release Time (typical) Minimum operations 1 x 107 1 x 105 at 5 A 250 VAC Res. 8 ms at nominal coil voltage 5 ms at nominal coil voltage (with no coil suppression) Max. switched power: 90 W or 750 VA Max. switched current: 3 A Max.
