Datasheet Summary
16 AMP HIGH TEMPERATURE POWER RELAY
Features
- 18.4 Amp switching capability
- Operating ambient temperature up to 105°C (221°F)
- 5 kV dielectric strength, Isolation spacing ≥ 10 mm
- Reinforced insulation according IEC 60730-1, IEC 60335-1
- Glow wire approved versions acc. IEC 60335-1 available
- pact size, low seated height of 15.7 mm
- UL / CUR file E44211
- VDE certificate 40006031
CONTACTS
Arrangement
SPST-NO (1 Form A) SPDT (1 Form C)
Ratings (max.) switched power switched current switched voltage
(resistive load) 4600 VA (2770 VA for sensitive coil versions) 18.4 A (10 A for sensitive coil versions) 125 VDC- or 440 VAC
- Note: If switching voltage is greater than...
