Datasheet Summary
60 AMP LATCHING
POWER RELAY
Features
- Low cost
- 60 Amp switching
- Heavy loads to 15,000VA
- 4kV dielectric
- Epoxy sealed construction available
- UL, CUR file E43203
CONTACTS
Arrangement Ratings
SPST (1 Form A), SPST (1 Form B)Not UL
Resistive load: Max. switched power: 15,000VA Max. switched current: 60A designs GENERAL DATA
Life Expectancy Mechanical Electrical
Set and Reset
Minimum operations 1 x 106 1 x 105 at 40A 250VAC Res.
Rated Load UL, CUR
Material w Resistance
Max. switched voltage: 250VAC 60A at 250VAC, 6k cycles, General Use 70°C 50A at 250VAC, 10k cycles, General Use 70°C 40A at 250VAC, 100k cycles, General Use 70°C
Silver tin oxide
< 50 milliohms initially...
