BQ24073 - Standalone 1-Cell 1.5-A Linear Battery Charger

This page provides the datasheet information for the BQ24073, a member of the BQ24072 Standalone 1-Cell 1.5-A Linear Battery Charger family.

Product Overview

Texas Instruments

📥 Download Datasheet

Datasheet Details

Part number	BQ24073
Manufacturer	Texas Instruments
File Size	3.54 MB
Description	Standalone 1-Cell 1.5-A Linear Battery Charger
Datasheet	BQ24073 Datasheet
Additional preview pages of the BQ24073 datasheet.

BQ24073 Product details

Description

The BQ2407x series of devices are integrated Li-Ion linear chargers and system power path management devices targeted at space-limited portable applications.

The devices operate from either a USB port or an AC adapter and support charge currents up to 1.5 A.

Features

Fully compliant USB charger.
Selectable 100-mA and 500-mA maximum input current.
100-mA Maximum current limit ensures compliance to USB-IF standard.
Input-based dynamic power management (VINDPM) for protection against poor USB sources.
Functional Safety-Capable (BQ24074).
Documentation available to aid functional safety system design.
28-V Input rating with overvoltage protection.
Integrated dynamic power path management (D.
