DP83869HM Overview
Key Specifications
Package: VQFN
Pins: 48
Max Voltage (typical range): 3.45 V
Min Voltage (typical range): 990 mV
Description
The DP83869HM device is a robust, fully-featured gigabit physical layer (PHY) transceiver with integrated PMD sublayers that supports 10BASE-Te, 100BASE-TX and 1000BASE-T Ethernet protocols. The DP83869 also supports 1000BASE-X and 100BASE-FX fiber protocols.
Key Features
- Multiple operating modes – Media support: copper and fiber – Media conversion between copper and fiber – Bridge between RGMII and SGMII
- Maximum ambient temperature available of 125°C
- Exceeds 8kV IEC61000-4-2 ESD
- Low power consumption – < 150mW for 1000Base-X – < 500mW for 1000Base-T
- Low RGMII latency – Total latency ≤ 384ns for 1000Base-T – Total latency ≤ 361ns for 100Base-TX
