bq25A - 1-4 Cell Li+ Battery SMBus Charge Controller

Download the bq25A datasheet PDF. This datasheet also covers the bq24725A variant, as both devices belong to the same 1-4 cell li+ battery smbus charge controller family and are provided as variant models within a single manufacturer datasheet.

General Description

The BQ24725A is a high-efficiency, synchronous battery charger, offering low component count for space-constraint, multi-chemistry battery charging applications.

Key Features

  • 1 SMBus Host-controlled NMOS-NMOS synchronous buck converter with programmable 615kHz, 750kHz, and 885kHz switching frequencies.
  • Automatic N-channel MOSFET selection of system power source from adapter or battery driven by internal charge pumps.
  • Enhanced safety features for over voltage protection, over current protection, battery, inductor and MOSFET short circuit protection.
  • Programmable input current, charge voltage, charge current limits.
  • ±0.5% Ch.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (bq24725A-etcTI.pdf) that lists specifications for multiple related part numbers.

📁 Similar Datasheet

Part Number Description Manufacturer
bq2502 Integrated Backup Unit BENCHMARQ
BQ2540-7R 60...132 Watt DC-DC Converters Power-One
BQ2001-7R 60...132 Watt DC-DC Converters Power-One
BQ2002 NiCd/NiMH Fast-Charge Management Benchmarq
BQ2002C NiCd/NiMH Fast-Charge Management UNITRODE

Other Datasheets by Texas Instruments

Part Number Description
bq25010 SINGLE-CHIP CHARGER AND DC/DC CONVERTER
bq25011 SINGLE-CHIP CHARGER AND DC/DC CONVERTER
bq25012 SINGLE-CHIP CHARGER AND DC/DC CONVERTER
bq25015 SINGLE-CHIP CHARGER AND DC/DC CONVERTER
bq25017 SINGLE-CHIP CHARGER AND DC/DC CONVERTER

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Product Folder Order Now Technical Documents Tools & Software Support & Community BQ24725A SLUSAL0C – SEPTEMBER 2011 – REVISED JANUARY 2020 BQ24725A SMBus 1- to 4-Cell Li+ Buck Battery Charge Controller with N-Channel Power MOSFET Selector 1 Features •1 SMBus Host-controlled NMOS-NMOS synchronous buck converter with programmable 615kHz, 750kHz, and 885kHz switching frequencies • Automatic N-channel MOSFET selection of system power source from adapter or battery driven by internal charge pumps • Enhanced safety features for over voltage protection, over current protection, battery, inductor and MOSFET short circuit protection • Programmable input current, charge voltage, charge current limits – ±0.5% Charge voltage accuracy up to 19.2V – ±3% Charge current accuracy up to 8.
