BAT760
BAT760 is Medium power Schottky barrier single diode manufactured by Nexperia.
Medium power Schottky barrier single diode
1 October 2022
Product data sheet
1. General description
Planar medium power Schottky barrier single diode with an integrated guard ring for stress protection, encapsulated in a very small SOD323 (SC-76) Surface-Mounted Device SMD plastic package.
2. Features and benefits
- Ultra high-speed switching
- Very low forward voltage
- Guard-ring protected
- Very small SMD plastic package
3. Applications
- Ultra high-speed switching
- Voltage clamping
- Protection circuits
4. Quick reference data
Table 1. Quick reference data
Symbol
Parameter
VR reverse voltage
IF forward current
VF forward voltage
Conditions
IF = 1 A; tp ≤ 300...
