BC850C - NPN transistor

General Description

NPN transistor in a small SOT23 Surface-Mounted Device (SMD) plastic package.

2.

Key Features

  • Low current (max. 100 mA).
  • Low voltage (max. 45 V).
  • AEC-Q101 qualified 3.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
BC850C NPN Transistors Kexin
BC850C Transistor LGE
BC850C NPN Silicon AF Transistors Infineon
BC850C NPN general purpose transistors NXP
BC850C NPN Silicon AF Transistors Siemens Semiconductor Group

Other Datasheets by Nexperia

Part Number Description
BC850B NPN transistor
BC856 PNP Transistor
BC856-Q 100mA PNP transistors
BC856A PNP Transistor
BC856A-Q 100mA PNP transistors

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
BC850C NPN general purpose transistor 25 April 2023 Product data sheet 1. General description NPN transistor in a small SOT23 Surface-Mounted Device (SMD) plastic package. PNP complement: BC860C 2. Features and benefits • Low current (max. 100 mA) • Low voltage (max. 45 V) • AEC-Q101 qualified 3. Applications • General purpose switching and amplification 4. Quick reference data Table 1. Quick reference data Symbol Parameter VCEO collector-emitter voltage IC collector current hFE DC current gain Conditions open base VCE = 5 V; IC = 10 µA; Tj = 25 °C Min Typ Max Unit - - 45 V - - 100 mA - 450 - 5. Pinning information Table 2.
