2SA1774G Datasheet | onsemi

Features - Reduces Board Space - High h FE, 210- 460 (typical) - Low VCE(sat), < 0.5 V - Available in 8 mm, 7- inch/3000 Unit Tape and Reel - S Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC- Q101 Qualified and PPAP Capable - These Devices are Pb- Free, Halogen Free/BFR Free and are Ro HS pliant MAXIMUM RATINGS (TA = 25C) Rating Symbol Value Unit Collector - Emitter Voltage Collector - Base Voltage Emitter - Base Voltage Collector Current - Continuous V(BR)CBO V(BR)CEO V(BR)EBO - 60 - 50 - 6.0 - 100 Vdc Vdc Vdc m Adc THERMAL CHARACTERISTICS Characteristic Symbol Max Unit Power Dissipation (Note 1) 150 m W Junction Temperature C Storage Temperature Range Tstg - 55 ~ + 150 C Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality should not be assumed, damage may occur and reliability may be affected. 1. Device mounted on a FR- 4 glass epoxy printed circuit board using the minimum remended footprint. SC- 75/SOT- 416 CASE 463 STYLE...
