BSP19A Datasheet NPN Silicon Expitaxial Transistor

Manufacturer: onsemi

Overview: BSP19A NPN Silicon Expitaxial Transistor This family of NPN Silicon Epitaxial transistors is designed for use as a general purpose amplifier and in switching applications. The device is housed in the SOT−223 package which is designed for medium power surface mount applications.

Datasheet Details

Part number BSP19A
Manufacturer onsemi
File Size 112.59 KB
Description NPN Silicon Expitaxial Transistor
Datasheet BSP19A-onsemi.pdf

Key Features

  • High Voltage.
  • The SOT-223 Package Can Be Soldered Using Wave or Reflow.
  • SOT-223 Package Ensures Level Mounting, Resulting in Improved Thermal Conduction, and Allows Visual Inspection of Soldered Joints.
  • The Formed Leads Absorb Thermal Stress During Soldering, Eliminating the Possibility of Damage to the Die.
  • PNP Complement is BSP16T1G.
  • Moisture Sensitivity Level (MSL): 1.
  • NSV Prefix for Automotive and Other.
