MMBT2907AWT1G
MMBT2907AWT1G is General Purpose PNP Silicon Transistor manufactured by onsemi.
General Purpose Transistor
PNP Silicon
MMBT2907AWT1G, NSVMMBT2907AWT1G
These transistors are designed for general purpose amplifier applications. They are housed in the SC- 70/SOT- 323 package which is designed for low power surface mount applications.
Features
- NSV Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements; AEC- Q101 Qualified and PPAP Capable
- These Devices are Pb- Free, Halogen Free/BFR Free and are RoHS pliant
MAXIMUM RATINGS
Rating
Symbol Value
Unit
Collector
- Emitter Voltage Collector
- Base Voltage Emitter
- Base Voltage Collector Current
- Continuous THERMAL CHARACTERISTICS
VCEO VCBO VEBO
- 60
- 60
- 5.0
- 600
Vdc Vdc...
