PE42420 Datasheet Spdt Rf Switch

Manufacturer: pSemi

Overview: PE42420 Document category: Product Specification UltraCMOS® SPDT RF Switch, 20–6000.

Datasheet Details

Part number	PE42420
Manufacturer	pSemi
File Size	2.13 MB
Description	SPDT RF Switch
Datasheet	PE42420-pSemi.pdf

General Description

The PE42420 is a HaRP™ technology-enhanced absorptive SPDT RF switch designed for use in 3G/4G wireless infrastructure and other high-performance RF applications.

This general-purpose switch consists of two symmetric RF ports with exceptional port-to-port isolation up to 6 GHz.

An integrated CMOS decoder provides an easy two-pin, low-voltage CMOS control interface.

Key Features

HaRP™ technology enhanced: No gate or phase lag No drift in insertion loss and phase High linearity: IIP3 of 65 dBm High isolation: 69 dB @ 1 GHz 62 dB @ 3 GHz 50 dB @ 6 GHz Supports +1.8V control logic +125 °C operating temperature High ESD tolerance: 4 kV HBM on RFC 2 kV HBM on all other pins Packaging: 20-lead 4 × 4 mm LGA.
