| Part Number | NE555D Datasheet |
|---|---|
| Manufacturer | Texas Instruments |
| Overview |
These devices are precision timing circuits capable of producing accurate time delays or oscillation. In the time-delay or mono-stable mode of operation, the timed interval is controlled by a single e.
*1 Timing From Microseconds to Hours * Astable or Monostable Operation * Adjustable Duty Cycle * TTL-Compatible Output Can Sink or Source Up to 200 mA * On Products Compliant to MIL-PRF-38535, All Parameters Are Tested Unless Otherwise Noted. On All Other Products, Production Processing Does Not Nec. |
NE555D Datasheet and Specifications PDF
The NE555D is a Precision Timer.
Key Specifications
| Package | SOIC |
|---|---|
| Mount Type | Surface Mount |
| Pins | 8 |
| Max Voltage (typical range) | 16 V |
| Min Voltage (typical range) | 4.5 V |
| Height | 1.75 mm |
| Length | 4.9 mm |
| Width | 3.91 mm |
| Part Number | NE555D Datasheet |
|---|---|
| Description | Single Timer |
| Manufacturer | Fairchild Semiconductor |
| Overview |
The LM555/NE555/SA555 is a highly stable controller capable of producing accurate timing pulses. With a monostable operation, the time delay is controlled by one external resistor and one capacitor. W.
* High Current Drive Capability (200mA) * Adjustable Duty Cycle * Temperature Stability of 0.005%/°C * Timing From µSec to Hours * Turn off Time Less Than 2µSec Applications * Precision Timing * Pulse Generation * Time Delay Generation * Sequential Timing Description The LM555/NE555/SA555 is a high. |
| Part Number | NE555D Datasheet |
|---|---|
| Description | CMOS GENERAL PURPOSE TIMER |
| Manufacturer | HTC KOREA |
| Overview |
The NE555 is CMOS RC timers providing significantly improved performance over the standard SE/NE555 and 355 timers, while at the same time being direct replacements for those devices in most applicati.
* Exact equivalent in most cases for SE/NE555 * Low Supply Current * High speed operation * 500KHz guaranteed * Wide operation supply voltage range - 2V to 18V * Timing from microseconds through hours * Operates in both astable and monostable modes * Adjustable duty cycle * High output source/sink d. |
