HOA6970 Datasheet Transmissive Optoschmitt Sensor

Manufacturer: Honeywell

Download the HOA6970 datasheet PDF. This datasheet also includes the HOA6961 variant, as both parts are published together in a single manufacturer document.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (HOA6961-Honeywell.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number HOA6970
Manufacturer Honeywell
File Size 920.50 KB
Description Transmissive Optoschmitt Sensor
Download HOA6970 Download (PDF)

General Description

The HOA696X/697X series consists of an infrared emitting diode facing an Optoschmitt detector encased in a black thermoplastic housing.

Detector switching takes place whenever an opaque object passes through the slot between emitter and detector.

The photodetector consists of a photodiode, amplifier, voltage regulator, Schmitt trigger and various output configurations.

Overview

HOA696X/697X Transmissive Optoschmitt Sensor.

Key Features

  • Direct TTL interface.
  • Buffer or inverting logic available.
  • Three device output options.
  • Four mounting configurations.
  • Choice of detector aperture.
  • 0.125 in. (3.18 mm) slot width.
