AACT212F Datasheet, Switch, ADV

AACT212F Features

• Switch
• Repetitive Peak Off-State Voltage: 1000Vand1200V
• R.M.S On-State Current ( IT(RMS)=2A )
• Very high immunity to false turn-on by dV/dt
• Triggering in t

PDF File Details

Part number:

AACT212F

Manufacturer:

ADV

File Size:

253.07kb

Download:

📄 Datasheet

Description:

Ac thyristor triac power switch. Available either in through-hole or surface-mount packages, the AACT2 suitable for general purpose AC switching. They can be used as

AACT212F Application

• Applications such as static relays, heating regulation,induction motor starting circuits or for phase control operation in light dimmers,motor speed
