AF7530M Datasheet - AFSEMI

AF7530M - 150mA Low Power LDO

The AF75XXM series is a set of three-terminal low power high voltage regulators implemented in CMOS technology.

They allow input voltages as high as 15V.

They are available with several fixed output voltages ranging from 2.1V to 6.0V.

CMOS technology ensures low voltage drop and low quiescent curre

AF7530M Features

* Low power consumption

* Low voltage drop

* Low temperature coefficient AF75XXM 150mA Low Power LDO

* High input voltage (up to 15V)

* Output voltage accuracy: tolerance ±2%

* SOT89 and SOT23 package Applications

* Battery-powered equipment

* Communication equipmen

AF7530M-AFSEMI.pdf

Preview of AF7530M PDF
AF7530M Datasheet Preview Page 2 AF7530M Datasheet Preview Page 3

Datasheet Details

Part number:

AF7530M

Manufacturer:

AFSEMI

File Size:

1.12 MB

Description:

150ma low power ldo.
