AF7533M

150mA Low Power LDO

AF7533M Features

* Low power consumption

* Low voltage drop

* Low temperature coefficient AF75XXM 150mA Low Power LDO

* High input voltage (up to 15V)

* Output voltage accuracy: tolerance ±2%

* SOT89 and SOT23 package Applications

* Battery-powered equipment

* Communication equipmen

AF7533M General Description

The AF75XXM series is a set of three-terminal low power high voltage regulators implemented in CMOS technology. They allow input voltages as high as 15V. They are available with several fixed output voltages ranging from 2.1V to 6.0V. CMOS technology ensures low voltage drop and low quiescent curre.

AF7533M Datasheet (1.12 MB)

Preview of AF7533M PDF

Datasheet Details

Part number:

AF7533M

Manufacturer:

AFSEMI

File Size:

1.12 MB

Description:

150ma low power ldo.
