APW8815 Datasheet, Controller, ANPEC

APW8815 Features

• Controller
• Adjustable Output Voltage from +0.75V to +5.5V - 0.75V Reference Voltage - ±1% Accuracy Over-Temperature General Description The APW8815 is a single-phase, constant-on-time,

PDF File Details

Part number:

APW8815

Manufacturer:

ANPEC

File Size:

563.50kb

Download:

📄 Datasheet

Description:

High-performance notebook pwm controller. The APW8815 is a single-phase, constant-on-time, synchronous PWM controller, which drives N-channel MOSFETs. The APW8815 steps down h

APW8815 Application

• Applications The Power-OnReset function monitors the voltage on VCC and PVCC to prevent wrong operation during power-on. The APW8815 has a 1.2ms di
