AP240N03NF Datasheet - APM

30V N-Channel Enhancement Mode MOSFET

AP240N03NF Features

* VDS = 30V ID =240A RDS(ON) < 0.85mΩ @ VGS=10V（Type：0.65mΩ） Application Buck Boost Package Marking and Ordering Information Product ID Pack Marking AP240N03NF PDFN5

* 6-8L AP240N03NF XXX YYYY Absolute Maximum Ratings (TC=25℃unless otherwise noted) Symbol Parameter Max. VDSS VGSS ID@TC

AP240N03NF General Description

AP240N03NF 30V N-Channel Enhancement Mode MOSFET The AP240N03NF uses advanced APM-SGT V technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Feat.

AP240N03NF Datasheet (952.23 KB)

AP240N03NF Datasheet Preview — Preview of AP240N03NF PDF

Datasheet Details

Part number:

AP240N03NF

Manufacturer:

APM

File Size:

952.23 KB

Description:

30v n-channel enhancement mode mosfet.
