ATA5771C - UHF ASK/FSK Transmitter

Product Overview

ATMEL

Datasheet Details

Part number	ATA5771C
Manufacturer	ATMEL
File Size	2.65 MB
Description	UHF ASK/FSK Transmitter
Datasheet	ATA5771C Datasheet
Additional preview pages of the ATA5771C datasheet.

Product details

Description

The Atmel® ATA5771C/73C/74C is a highly flexible programmable transmitter containing the Atmel AVR® microcontroller Atmel ATtiny44V and the UHF PLL transmitters in a small QFN24 5mm × 5mm package.

Features

Atmel® AVR® microcontroller and RF transmitter PLL in a single QFN24 5mm × 5mm package (pitch 0.65mm).
Operating frequency ranges 310MHz to 350MHz, 429MHz to 439MHz and 868MHz to 928MHz.
Temperature range.
40°C to +85°C.
Supply voltage 2.0V to 3.6V allowing usage of single Li-cell power supply.
Low power consumption.
Active mode: typical 9.8mA at 3.0V and 4MHz microcontroller-clock.
Power-down mode: Typical 200nA at 3.0V.
Modulation scheme ASK/FSK.
