ACM1602B Datasheet - AZ Displays

ACM1602B - SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY

Executing time fosc=250khz 1.64ms 1.64ms Clear Display Cursor at Home 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 x Clears Display & Returns to Address 0. Returns Cursor to Address 0. Also returns the display being shifted to the original position. DDRAM contents remain unchanged. I/D: Set Curs.
AZ DISPLAYS, INC. COMPLETE LCD SOLUTIONS SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY PART NUMBER: DATE: ACM 1602B SERIES August 9, 1999 ACM1602B SERIES LCD MODULE 1.0 MECHANICAL SPECS 1. Overall Module Size 84.0mm(W) x 44.0mm(H) x max 13.5mm(D) for LED backlight version 84.0mm(W) x 44.0mm(H) x max 9.5mm(D) for reflective version 2. Dot Size 3. Dot Pitch 4. Duty 5. Controller IC 6. LC Fluid Options 7. Polarizer Options 8. Backlight Options 9. Temperature Range Options 0.56mm(W) x 0.61mm(H) 0.61.
