v3.1
54SX Family FPGAs
Le a di ng E dg e P er f or m a nc e F ea t u r es
• 320 MHz Internal Performance • 3.7 ns Clock-to-Out (Pin-to-Pin) • 0.1 ns Input Set-Up • 0.25 ns Clock Skew
Sp e ci f ic at ion s
• 66 MHz PCI • CPLD and FPGA Integration • Single Chip Solution • 100% Resource Utilization with 100% Pin Locking • 3.3V Operation with 5.0V Input Tolerance • Very Low Power Consumption • Deterministic, User-Controllable Timing • Unique In-System Diagnostic and Debug capability with Silicon Explorer II • Boundary Scan Testing in Compliance with IEEE Standard 1149.1 (JTAG) • Secure Programming Technology Prevents Reverse Engineering and Design Theft
• 12,000 to 48,000 System Gates • Up to 249 User-Programmable I/O Pins • Up to 1080 Flip-Flops • 0.
A54SXxx Datasheet
