ACT91, ACT90 Datasheet - Advanced Crystal Technology

ACT91 (ACT90 / ACT91) miniature surface mount Watch Crystal

Tel : Fax : email : 0044 (0)118 979 1238 0044 (0)118 979 1283 info@actcrystals.com ACT90 & 91CSMX The ACT90 & 91are miniature surface mount Watch Crystal whose low power consumption makes them ideal for portable applications. Their size makes them suitable for high density circuit boards or applications where space is limited and the tape and reel packaging means that they are ideal for automatic placement machines. The heart of the device is a heat resistant cylinder type crystal which gives .

ACT90_AdvancedCrystalTechnology.pdf

This datasheet PDF includes multiple part numbers: ACT91, ACT90. Please refer to the document for exact specifications by model.
ACT91 Datasheet Preview Page 2 ACT91 Datasheet Preview Page 3

Datasheet Details

Part number:

ACT91, ACT90

Manufacturer:

Advanced Crystal Technology

File Size:

325.71 KB

Description:

(act90 / act91) miniature surface mount watch crystal.

Note:

This datasheet PDF includes multiple part numbers: ACT91, ACT90.
Please refer to the document for exact specifications by model.
