FS361-xxx, Low Insertion Force PGA Sockets

www.DataSheet4U.com Low Insertion Force PGA Sockets 5 Energy Way, P.O.Box 1019, West Warwick, RI 02893 USA Tel.800-424-9850/401-823-5200 *.

datasheet Preview Page 1 from Datasheet4u.com

FS361-xxx_AdvancedInterconnections.pdf

FS361-xxx Datasheet Preview — Preview of FS361-xxx PDF

Datasheet Details

Part number:

FS361-xxx

Manufacturer:

Advanced Interconnections

File Size:

174.09 KB

Description:

Low Insertion Force PGA Sockets

Features

* As low as 1 oz. (28.34 g) average insertion force per pin.
* Multiple finger contacts for reliability.
* Over 500 PGA footprints available.
* Closed bottom terminal for 100% antiwicking of solder.
* Tapered entry for ease of insertion.
* To fit .100”

Applications

* For custom solder preform terminal applications consult factory.
* See previous page for material specifications and how to order information. Preform After Solder Flow Solder Preform Terminals Type -150 .072 Dia. (1.83) Type -151 .072 Dia. (1.83) .072 Dia. (1.83) .165 .165 (
