FS361 One Cell Lithium-ion/Polymer Battery Protection IC

The FS361 battery protection IC is designed to protect lithium-ion/polymer battery from damage or degrading the lifetime due to overcharge, overdischarge for one-cell lithium-ion/polymer battery powered systems, such as cellular phones. The ultra-small package and less required external components m.

REV. 1.1 FS361-DS-11_EN SEP 2011 For RefPerrFoepOnecRrteTieUOsnNlEy' Datasheet FS361 One Cell Lithium-ion/Polymer Battery Protection IC Fortune Semiconductor Corporation 28F,No. 27, Sec. 2, Zhongzheng E. Rd., Danshui Dist, New Taipei City 251, Taiwan Tel.：886-2-28094742 Fax：886-2-28094874 www.ic-fortune.com FS361 For RefPerrFoepOnecRrteTieUOsnNlEy' This manual contains new product information. Fortune Semiconductor Corporation reserves the rights to modify the product specification witho.

FS361 Features

* Reduction in Board Size due to Miniature Package SOT-23-6. Supply Current at 3μ A (Vcc=3.65V). Power-Down Current at 0.1μ A (Vcc=1.9V). Precision Overcharge Protection Voltage VOCP ± 50mV Load Detection Function during Overcharge Mode. Delay times are generated by internal circuits. No external capa
