FS326

One Cell Lithium-ion/Polymer Battery Protection IC

FS326 Features

* Low supply current Normal Operation : 3.0μA typ. @VDD=3.9V Power-down mode : 0.1μA max. @VDD=2.0V Overcharge detection voltage 4.2V~4.4V, Accuracy of ±25mV ﹝VOCU﹞ Overcharge release voltage 3.8V~4.2V, Accuracy of ±50mV ﹝VOCR﹞ Overdischarge detection voltage 2.2V~2.9V, Accuracy of ±50

* mV

FS326 General Description

FS326 is a series of lithium-ion and lithium-polymer rechargeable battery protection ICs with high accurate voltage detection and delay circuits. These ICs are suitable for protection of single cell lithium-ion or lithium polymer battery packs from over charge, over discharge and over current. 2..

FS326 Datasheet (633.02 KB)

Preview of FS326 PDF

Datasheet Details

Part number:

FS326

Manufacturer:

Fortune

File Size:

633.02 KB

Description:

One cell lithium-ion/polymer battery protection ic.
REV. 2.0 FS326-DS-20_EN JUL 2009 For RefPerroepnecFrteSieCO’snly Datasheet FS326 One Cell Lithium-ion/Polymer Battery Protection IC Fortune Semico.
