FS325

One Cell Lithium-ion/Polymer Battery Protection

FS325 Features

* Low supply current Normal Operation : 2.5μA typ. @VDD=3.9V Power-down mode : 0.05μA typ. @VDD=2.0V Auto recovery function : 1.8 μ A typ. @VDD=2.0V

* Overcharge detection voltage﹝VOCU﹞ 4.25V~4.31V, Accuracy of 25mV

* Overcharge release voltage﹝VOCR﹞ 4.05V~4.11V, Accuracy of 50mV

FS325 General Description

FS325 is a series of lithium-ion and lithium-polymer rechargeable battery protection ICs with high accurate voltage detection and delay circuits. These ICs are suitable for protection of single cell lithium-ion or lithium polymer battery packs from over charge, over discharge and over current. 2. Fe.

FS325 Datasheet (1.28 MB)

Preview of FS325 PDF

Datasheet Details

Part number:

FS325

Manufacturer:

Fortune

File Size:

1.28 MB

Description:

One cell lithium-ion/polymer battery protection.
REV. 1.9 FS325-DS-19_EN JUN 2015 For RefPerrFoepOnecRrteTieUOsnNlEy' Datasheet FS325 One Cell Lithium-ion/Polymer Battery Protection IC For RefPer.
