Part number: STRF6600
Manufacturer: Allegro Micro Systems
File Size: 319.64KB
Download: 📄 Datasheet
Description: Off-line Quasi-resonant Flyback Switching Regulators
The series is provided in a five-pin overmolded TO-3P style package, affording dielectric isolation without compromising thermal characteristics.
2
3
VIN
1
OVER-CUR.
from battery chargers and set top boxes, to televisions, monitors, and industrial power supply units. Cycle-by-cycle cu.
and Operation
The voltage on the VIN terminal (pin 4) controls startup and shutdown of the Series STR-F6600 devices. Figure 1 shows a typical start up circuit. The VIN terminal voltage during startup is shown in figure 2.
At startup, C2 is charged .
